IPC-606D is a compact dimension industrial computer with an Intel® J1900 processor, dual GbE LAN, 4 x COM ports, 4 x USB ports, 1xmSATA bay. DC 9-36V wide power input, wide operating temperature, economic and reliable, it will be fit for IOT terminal and manufacture application.


Specifications

Processor	CPU	Intel Baytrail-D Celeron J1900, 2.0~2.42GHz, 4cores, 4threads, 2M cache, 22nm,TDP 10W
	Cooling System	Fanless
	Memory	Onboard DDR3L, max 4GB
	Storage	mSATA SSD Full Size
	I/O ports	3xUSB2.0+1xUSB3.0, Type-A
		COM: 4xRS232, DB9, 2*RS485 optional
		Dual Display: 1xHDMI (3840*2160 @30Hz) 1*VGA (1920*1200 @30Hz)
		Audio: 1xMic-in, 1x Line-out
		WIFI: 802.11a/g/n, 2x2 Antenna, 2.4/5 GHz, 300 Mbps Max Speed
	Network(LAN)	2x Intel I211 10/100/1000Mbps Ethernet
Power Supply	Input Voltage	12V DC (2 Pin Aviation Connector) , optional 9V-36V DC
Control SW	Control SW	1xPower SW (Rear), AT/ATX optional
OS Support	OS Support	Windows 7, Windows 8.1, Windows 10, Linux Ubuntu
Environment	Operating   Temperature	-10℃～60℃(14~ 140 °F)(extend temperature optional)
	Storage   Temperature	-20℃～75℃(-4 ~ 167 °F) (extend temperature optional)
Mechanical	Dimensions	(W*D*H): 190*156*46mm
	Weight(G.W.)	N.W. 1.5KG(3.3lb)
	Color	Black
	Material	High Strength Aluminum Alloy
Custom Service	Custom   Service	Custom BIOS, System Encryption, Custom LOGO
